DHY9KSEM

DHY9KSEM

SPECIFICATIONS

Model	DHY9KSEM
Power Output kW/kVA	Prime Power 8kW/10kVA Stand By Power 8.8kW/11kVA
Start	Electric
Engine Displacement CC	1357cc
Engine Make	Hyundai
Engine Type	11hp HY380 diesel engine
Fuel Tank Capacity	42 Litres
Fuel Type	Diesel
Features	digital Display on Control Panel
Noise Level in dB(A)	65dB(A) @ 7m
Oil Tank Capacity	10L
Run Time	23 Hours @ 50% Load
Voltage 50Hz	230
Connection Method	Hard Wire / 1 x 32A 1 x 15A IP67 Outlets
Warranty	1 Year Hyundai Warranty
Dimensions L x W x H (mm)	1500 x 760 x 1070
Weight	530 kg

Description

The Hyundai DHY9KSEm is a single phase diesel generator with a maximum output of 8.8kW. Designed for standby use for your home or business, the DHY9KSEm is powered by an 11hp HY380 diesel engine and is equipped an AVR alternator to produce clean energy. This means that any sensitive electronic equipment, such as televisions, PCs and laptops, can safely be powered by the DHY9KSEm.

The DHY9KSEm can be started manually by using the key, or connected to an ATS (Automatic Transfer Switch) system. An ATS system will automatically detect a loss of power from the mains, turn your DHY9KSEm on automatically, and then turn it off again when power returns from the mains.

Housed in a weather-proof “silenced” canopy, the DHY9KSEm produces only 65dB @ 7 metres which makes it a quiet standby generator which won’t interrupt you at home or work.

The DHY9KSEm benefits from being an economical diesel generator, capable of running on red diesel which is significantly cheaper than road diesel and is safer to store than petrol.

Running at 1500rpm, the engine is stressed less than in 3000rpm generators and this helps extend the lifespan of the machine if properly serviced.

Please contact us for more details on this model, and other generators in our range.
